SAMSUNG OH46F 46IN FULL HD OUTDOOR SIGNAGE DISPLAY

OH46F
[Contact us for a price] Request a quote
For Special & Volume Pricing – Call 1800 419 5553

Need Help

Choosing a Product
1800 419 5553 Live Chat Email Us
Talk to our technical Expert
price match

Description

SAMSUNG OH46F 46IN FULL HD OUTDOOR SIGNAGE DISPLAY

Ultra High Brightness Display for Outdoor Applications - Weather Proof / External Power Supply with 2500 NITS/ IP56 Ingress Protection.

Features :
  • All-in-one solution complete with an embedded power box, along with an ultra-slim depth of 85mm
  • An optimum level of endurance equivalent to IK10 and extra durability with IP56 Ingress Protection
  • A filterless self-cooling system enabling easy maintenance and reduced TCO
  • Excellent visibility under direct sunlight through 2,500-nit high brightness and anti-reflection glass
  • An advanced content management solution via SSSP 4.0 powered by TIZEN
  • 2500 cd/m2 brightness rating and 5000:1 contrast ratio
  • Auto Brightness sensor
  • Circular polarizing technology to eliminate display blindness caused by polarized sunglasses
  • Anti-reflection glass for improved visibility under direct sunlight
  • Enhanced content management solution via SSSP 4.0 powered by TIZEN
  • MagicInfo S4 powered by Tizen helps in convenient content creation, scheduling, and deployment
  • Cortex-A12 1.3 GHz Quad Core CPU
  • Conforms to IK10 vandal-resistant and IP56 ingress protection standards

SPECIFICATIONS :

Display

Screen Size (Diagonal)

46"

Resolution

1920 x 1080

Panel Type

VA LCD

Bit Depth / Color Support

8-Bit (16.7 Million Colors)

Brightness

2500 cd/m²

Viewing Angle (H x V)

178 x 178°

Screen Area

40 x 22.5" / 101.6 x 57.2 cm

Contrast Ratio

5000:1

Dynamic Contrast Ratio

100,000:1

Response Time

6 ms

Horizontal Frequency

108 to 139.5 kHz

Vertical Frequency

96 to 123 Hz

Dot Pitch

0.53 x 0.53 mm

Pixel Clock Frequency

297 MHz

Connectivity

Input Ports

2 x HDMI 1.4 Audio, Video

Output Ports

1 x 1/8" / 3.5 mm – Audio

USB Ports

1 x USB 2.0

Ethernet Ports

1

General

HDCP Support

Yes, Version 2.2

Surface

Haze Level

0%

Audio

Processing

DTS

Hardware

Operating System

Tizen 2.4

Processor

1.3 GHz ARM Cortex A12 Quad-Core

Storage

8 GB

RAM

2.5 GB DDR3 1866 MHz

Convenience

Supported Video File Types

H.263, H.264/AVC, MPEG, MPEG2, MPEG4, VP8, VP9

Supported Audio File Types

AC3

Supported Photo File Types

JPEG, PNG

Electrical

Power Consumption

Maximum: 468.0 W
Typical: 410.0 W
Standby: 0.5 W

AC Input Power

100 to 240 VAC, 50 / 60 Hz

Environmental

Operating Temperature

-22 to 122°F / -30 to 50°C

Operating Humidity

10 to 80%

Physical

Material of Construction

5T Glass

Bezel Thickness

24.9 mm (Bottom)
24.9 mm (Right)
24.9 mm (Top)
24.9 mm (Left)

Duty Cycle

24 Hours / 7 Days

Dimensions

42.0 x 24.5 x 3.3" / 1069.0 x 623.6 x 85.0 mm

Weight

89.2 lb / 40.5 kg
