SAMSUNG PM55FBC 55IN FULL HD COMMERCIAL TOUCH SCREEN LED DISPLAY

PM55FBC
[Contact us for a price] Request a quote
For Special & Volume Pricing – Call 1800 419 5553

Need Help

Choosing a Product
1800 419 5553 Live Chat Email Us
Talk to our technical Expert
price match

Description

SAMSUNG PM55FBC 55IN FULL HD COMMERCIAL TOUCH SCREEN LED DISPLAY

High End Professional Display for AVSI & Digital Signage Projects - 24x7 Operation - 400/500 nits Brightness with Integrated Touch/ Capacitive Touch with 8GB Internal Storage and Multi Touch.

Features :
  • Capacitive touch technology that enables up to 10 different touch points simultaneously
  • Full HD (1920 x 1080) Native Resolution
  • 60 Hz Refresh Rate
  • 400 cd/m² Brightness
  • 4000:1 Contrast Ratio
  • Built-In Wi-Fi & Ethernet Connectivity
  • DVI-I, DisplayPort, 2 x HDMI Inputs
  • Daisy-Chaining via DisplayPort Out
  • Dual Built-In 10W Speakers
  • Up to 10 Touchscreen Points
  • Digital Signage Capable
  • All-in-one display solution with embedded MagicInfo Player S4 powered by Tizen™
  • IP5x certification that reflects it can withstand demanding usage environments

SPECIFICATIONS :

Display

Screen Size (Diagonal)

54.6"

Resolution

1920 x 1080

Panel Type

Unspecified LCD

Bit Depth / Color Support

8-Bit+FRC (1.07 Billion Colors)

Brightness

400 cd/m² (Typical)

Viewing Angle (H x V)

178 x 178°

Screen Area

47.62 x 26.79" / 1209.6 x 680.4 mm

Aspect Ratio

16:9

Contrast Ratio

4000:1

Response Time

8 ms

Refresh Rate

60 Hz

Horizontal Frequency

30 to 81 kHz

Vertical Frequency

48 to 75 Hz

Dot Pitch

0.630 x 0.630 mm

Backlighting Technology

Edge LED

Connectivity

Primary Connectivity Location

Display

Input Ports

2 x HDMI 2.0 Audio, Video
1 x DisplayPort 1.2 Audio, Video
1 x DVI-I Video
1 x 1/8" / 3.5 mm Audio

Output Ports

1 x DisplayPort 1.2 – Audio, Video
1 x 1/8" / 3.5 mm – Audio

USB Ports

1 x USB 2.0 Type-A - Audio/Photo/Video
1 x USB 2.0 Type-A - Touchscreen Control

Ethernet Ports

1

Control

RS-232C via 1/8" / 3.5 mm Input
RS-232C via 1/8" / 3.5 mm Output

Wi-Fi

Built-in

General

TV Tuner

Yes

Display Orientation

Landscape, Portrait

HDCP Support

Yes, Version 2.2

Maximum Multiple Display Configuration

15 x 15

Surface

Touchscreen Technology

Capacitive

Multi-Touch Points

10

Surface Treatment

Anti-Glare

Haze Level

35%

Audio

Built-In Speakers

Yes, 2 x 10 W

Speaker Configuration

2-Channel

Processing

Dolby Digital, DTS

Hardware

Operating System

Tizen 2.4

Processor

1.3 GHz ARM Cortex-A12 Quad-Core

Storage

8 GB

RAM

2.5 GB DDR3 1866 MHz

Convenience

Supported Video File Types

H.263, H.264/AVC, H.265/HEVC, MPEG, MPEG2, MPEG4, VC-1, VP8, VP9

Supported Audio File Types

AC3

Supported Photo File Types

JPEG, PNG

Electrical

Power Consumption

Maximum: 187.0 W
Typical: 125.0 W
Standby: < 0.5 W

AC Input Power

100 to 240 VAC, 50 / 60 Hz

Power Adapter Type

Internal

Physical

Wall Mounting

400 x 400mm

Material of Construction

3.2T Glass

IP Rating

IP5X

Bezel Thickness

25 mm (Bottom/Top)
17.9 mm (Right/Left)

Duty Cycle

24 Hours / 7 Days

Dimensions

49.1 x 28.8 x 2.3" / 124.7 x 73.2 x 5.8 cm

Weight

58.2 lb / 26.40 kg

Packaging Info

Package Weight

72 lb

Box Dimensions (LxWxH)

54 x 34 x 8"
