SAMSUNG PM55FBC 55IN FULL HD COMMERCIAL TOUCH SCREEN LED DISPLAY

[Contact us for a price] Request a quote
PM55FBC

Description

SAMSUNG PM55FBC 55IN FULL HD COMMERCIAL TOUCH SCREEN LED DISPLAY

High End Professional Display for AVSI & Digital Signage Projects - 24x7 Operation - 400/500 nits Brightness with Integrated Touch/ Capacitive Touch with 8GB Internal Storage and Multi Touch.

Features :
  • Capacitive touch technology that enables up to 10 different touch points simultaneously
  • Full HD (1920 x 1080) Native Resolution
  • 60 Hz Refresh Rate
  • 400 cd/m² Brightness
  • 4000:1 Contrast Ratio
  • Built-In Wi-Fi & Ethernet Connectivity
  • DVI-I, DisplayPort, 2 x HDMI Inputs
  • Daisy-Chaining via DisplayPort Out
  • Dual Built-In 10W Speakers
  • Up to 10 Touchscreen Points
  • Digital Signage Capable
  • All-in-one display solution with embedded MagicInfo Player S4 powered by Tizen™
  • IP5x certification that reflects it can withstand demanding usage environments

SPECIFICATIONS :

Display

Screen Size (Diagonal)

54.6"

Resolution

1920 x 1080

Panel Type

Unspecified LCD

Bit Depth / Color Support

8-Bit+FRC (1.07 Billion Colors)

Brightness

400 cd/m² (Typical)

Viewing Angle (H x V)

178 x 178°

Screen Area

47.62 x 26.79" / 1209.6 x 680.4 mm

Aspect Ratio

16:9

Contrast Ratio

4000:1

Response Time

8 ms

Refresh Rate

60 Hz

Horizontal Frequency

30 to 81 kHz

Vertical Frequency

48 to 75 Hz

Dot Pitch

0.630 x 0.630 mm

Backlighting Technology

Edge LED

Connectivity

Primary Connectivity Location

Display

Input Ports

2 x HDMI 2.0 Audio, Video
1 x DisplayPort 1.2 Audio, Video
1 x DVI-I Video
1 x 1/8" / 3.5 mm Audio

Output Ports

1 x DisplayPort 1.2 – Audio, Video
1 x 1/8" / 3.5 mm – Audio

USB Ports

1 x USB 2.0 Type-A - Audio/Photo/Video
1 x USB 2.0 Type-A - Touchscreen Control

Ethernet Ports

1

Control

RS-232C via 1/8" / 3.5 mm Input
RS-232C via 1/8" / 3.5 mm Output

Wi-Fi

Built-in

General

TV Tuner

Yes

Display Orientation

Landscape, Portrait

HDCP Support

Yes, Version 2.2

Maximum Multiple Display Configuration

15 x 15

Surface

Touchscreen Technology

Capacitive

Multi-Touch Points

10

Surface Treatment

Anti-Glare

Haze Level

35%

Audio

Built-In Speakers

Yes, 2 x 10 W

Speaker Configuration

2-Channel

Processing

Dolby Digital, DTS

Hardware

Operating System

Tizen 2.4

Processor

1.3 GHz ARM Cortex-A12 Quad-Core

Storage

8 GB

RAM

2.5 GB DDR3 1866 MHz

Convenience

Supported Video File Types

H.263, H.264/AVC, H.265/HEVC, MPEG, MPEG2, MPEG4, VC-1, VP8, VP9

Supported Audio File Types

AC3

Supported Photo File Types

JPEG, PNG

Electrical

Power Consumption

Maximum: 187.0 W
Typical: 125.0 W
Standby: < 0.5 W

AC Input Power

100 to 240 VAC, 50 / 60 Hz

Power Adapter Type

Internal

Physical

Wall Mounting

400 x 400mm

Material of Construction

3.2T Glass

IP Rating

IP5X

Bezel Thickness

25 mm (Bottom/Top)
17.9 mm (Right/Left)

Duty Cycle

24 Hours / 7 Days

Dimensions

49.1 x 28.8 x 2.3" / 124.7 x 73.2 x 5.8 cm

Weight

58.2 lb / 26.40 kg

Packaging Info

Package Weight

72 lb

Box Dimensions (LxWxH)

54 x 34 x 8"
