SAMSUNG QB75NW 75IN 4K UHD LED RS232 USB TOUCH DISPLAY

[Contact us for a price] Request a quote
QB75NW

Description

SAMSUNG QB75NW 75IN 4K UHD LED RS232 USB TOUCH DISPLAY

Eboard/ Touch 4K Professional Display for AVSI & Digital Signage Projects with / HDMI / DVI / RS232 / USB / RJ45 / Wi-Fi Ready / Built-in-Speakers / Inbuilt Media Player & MagicInfo with 8GB Internal Storage and Multi Touch.

Features :
  • Deliver a smooth, comfortable digital writing experience
  • Enable up to four participants to write simultaneously with any tool
  • Streamline efficient meeting facilitation via the embedded MagicIWB S5 solution
  • Alternate between content sources with an intuitive UX
  • UHD picture quality with ultra-realistic detail and clarity that amplifies content
  • Integrated TIZEN 3.0 operating system that improves overall business performance
  • Reinforced security measures that protect business and customer data
  • Improve real-time interaction and introduce new ideas through advanced connectivity
  • Elevate content quality with crisp UHD resolution
  • Enhance meeting room sophistication through a stylish, pristine design

SPECIFICATIONS :

Panel

Screen Size

75"

Type

120Hz Direct LED

Resolution

UHD (3840 x 2160)

Brightness (Typical)

300nit (w/o Touch Glass)

Contrast Ratio (Typical)

Mega

Viewing Angle (H/V)

178/178

Response Time (G to G)

8ms

Operation Hour

16/7

Sound

Speaker Type

Built in Speaker (10W x 2) (Down Firing w/Bass Reflex)

Connectivity

Input

Video: HDMI Rear1, HDMI Rear2 (ver 2.0), HDMI Front3 (ver 1.4), DVI-D
USB: USB 1, 2 (Rear), USB 3 (Front), PC USB (Front)

Output

Audio
Touch Out 1 (Rear), Touch Out 2 (Front)

External Control

RS232C (in/out) thru stereo jack, RJ45, Wi-Fi

External Sensor

IR Sensor (Display Control)

Touch

Type

IR (Infra Red)

# of Drawing

4 drawing (SoC), 10 drawing (External Windows PC)

Touch Pen Type

Passive Pen

Object Recognition Range

8mm

Touch Response Time

7ms (Single Touch)

Power

Type

Internal

Power Supply

AC 100~240V 50/60Hz

Power Consumption

Rating [W/h]: 200 (Max 220)
Typical [W/h]: 157
Stand-by (Max): 0.5

Environmental Conditions

Operating Temperature

0℃~ 40℃

Operating Humidity

10~80%

Features

Key

Slim & Light LFD with Built-in MagicInfo Player S5, SSSP

Special

Hardware: Super Clear Coating, Temperature Sensor, Pivot Display, Clock Battery (168hrs Clock Keeping), Built in Speaker(10W x 2), WiFi Module Embedded

Software: MagicIWB S5

Platform

Kant-M (Tizen 3.0)

Internal Player (Embedded H/W)

Processor

Coretex A72 1.7GHz Quad-Core CPU

On-Chip Cache Memory

L1 Instruction Cache : 48KB
L1 Data Cache : 32KB
L2 Cache : 2MB

Clock Speed

1.7GHz Quad-Core CPU

Main Memory Interface

3GB 3ch 64bit LPDDR4 1.6GHz

Graphics

2D & 3D Graphic Accelerator
Data Format : 32bpp
Output resolution : 3840x2160p

Storage (FDM)

8GB (3.88GB Occupied by O/S, 4.12GB Available)

Multimedia

*Video Decoder: MPEG 1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS/AVS+, MVC, VP8, VP9, HEVC, JPEG Audio DSP(Decoder), MPEG, AC3, AC4, DD, MP3 and etc

IO Ports

USB 2.0

Operating System

Tizen 3.0 (VDLinux)

Mechanical Spec

Without Stand (W x H x D)

1741.5 x 1012.1 x 81.2 mm

Package (WxHxD)

1905 x 1175 x 307 mm

Product Weight

57.4 kg

Package Weight

69.5 kg

Color

Black

VESA Mount

400 x 400

Protection Glass

Yes

Stand Type

Wall Mount

Media Player Option Type

N/A

Rotation

N/A

Power Cable Length

3m

Accessory

Pen Holder

Certification

Safety

60950-1

EMC

Class B

Environment

N/A

Service

Standard Warranty

3yr Onsite (Parts/Labor/Backlight)

Accessories

Included

Passive Pen, Power Cable

Optional

Stand: Optional
Mount: Optional
Specialty: New MagicIWB S5 UX
