SAMSUNG QM85N 85IN 4K UHD RS232 USB LED DISPLAY

QM85N
[Contact us for a price] Request a quote
For Special & Volume Pricing – Call 1800 419 5553

Need Help

Choosing a Product
1800 419 5553 Live Chat Email Us
Talk to our technical Expert
price match

Description

SAMSUNG QM85N 85IN 4K UHD RS232 USB LED DISPLAY

4K Mainstream Proff Display for AVSI&Digital Signage Projects with 24x7-500nits Brightness and Web Browsing / HDMI /DVI/ RS232 / USB / RJ45 / Wi-Fi Ready /Built-inSpeakers /EDGE LED/ Inbuilt MediaPlayer&MagicInfo S3.

Features :
  • Ultra-high brightness emphasizing content, regardless of the lighting conditions
  • Slim and contemporary design that seamlessly integrates into any display window
  • Easy content management with a built-in management solution
  • K UHD (3840 x 2160) Native Resolution
  • 8 ms Response Time
  • 500 cd/m² Brightness
  • 3000:1 Typical Contrast Ratio

SPECIFICATIONS :

Display

Screen Size (Diagonal)

84.5"

Resolution

3840 x 2160

Panel Type

Unspecified LCD

Brightness

500 cd/m² (Typical)

Viewing Angle (H x V)

178 x 178°

Screen Area

73.70 x 41.46" / 1872 x 1053 mm

Aspect Ratio

16:9

Contrast Ratio

3000:1

Response Time

8 ms (GtG)

Horizontal Frequency

30 to 81 kHz

Vertical Frequency

48 to 75 Hz

Dot Pitch

0.4875 x 0.4875 mm

Backlighting Technology

Direct LED

Connectivity

Primary Connectivity Location

Display

Input Ports

2 x HDMI 2.0 – Audio, Video (Side)
1 x DisplayPort 1.2 – Audio, Video (Side)
1 x DVI-D – Video (Side)
1 x 1/8" / 3.5 mm – Audio (Side)

Output Ports

1 x HDMI – Audio, Video (Side)
1 x 1/8" / 3.5 mm – Audio (Rear)

USB Ports

1 x USB (Version Unspecified) Type-A (Rear)
1 x USB (Version Unspecified) Type-A (Side)

Ethernet Ports

1 (Side)

Other I/O

1 x 1/8" / 3.5 mm Control Input (Side)
1 x 1/8" / 3.5 mm Control Output (Side)
1 x 1/8" / 3.5 mm IR Input (Rear)

Wi-Fi

Built-in

Bluetooth

Yes

Digital Media Slot

None

General

TV Tuner

No

Display Orientation

Landscape, Portrait

HDCP Support

Yes, Version 2.2

Surface

Surface Treatment

Anti-Glare

Haze Level

44%

Audio

Built-In Speakers

Yes, 2 x 15 W

Speaker Configuration

2-Channel

Hardware

Operating System

Tizen 4

Processor

1.7 GHz ARM Cortex A72 Quad-Core

Storage

8 GB Flash

RAM

2.5 GB LPDDR4 1500 MHz

Convenience

Supported Video File Types

H.263, H.264/AVC, H.265/HEVC, MPEG2, MPEG4, VC-1, VP8, VP9

Supported Audio File Types

AC3

Supported Photo File Types

JPEG, PNG

Electrical

Power Consumption

Maximum: 495.0 W
Typical: 362.0 W
Standby: 0.5 W

AC Input Power

100 to 240 VAC, 50 / 60 Hz

Power Adapter Type

Internal

Environmental

Operating Temperature

32 to 104°F / 0 to 40°C

Operating Humidity

10 to 80%

Physical

Wall Mounting

600 x 400mm

Bezel Thickness

13.2 mm (Right/Top/Left)
19.3 mm (Bottom)

Duty Cycle

24 Hours / 7 Days

Dimensions

74.9 x 42.9 x 4.1" / 1903.4 x 1090.5 x 105.1 mm

Weight

111.77 lb / 50.70 kg

Packaging Info

Package Weight

40 lb

Box Dimensions (LxWxH)

80.5 x 50 x 18.5"
