SAMSUNG UH46N-E 46IN EXTREME NARROW BEZEL VIDEOWALL DISPLAY

UH46N-E
[Contact us for a price] Request a quote
For Special & Volume Pricing – Call +91 92050 81551

Need Help

Choosing a Product
+91 92050 81551 Live Chat Contact Us
Talk to our technical Expert
price match

Description

SAMSUNG UH46N-E 46IN EXTREME NARROW BEZEL VIDEOWALL DISPLAY

Super Ultra Thin Bezel Video Wall panel with 1.7mm bezel-to-bezel - 700 nits brightness/ 25% HAZE Non Glare Panel.

Features :
  • Extremely narrow bezel (B-to-B 1.7mm) for a virtually seamless, life-like viewing experience
  • Superb color accuracy and brightness uniformity thanks to precise calibration and panel technology
  • Daisy Chain through use of DisplayPort (DP) 1.2 or HDMI port, eliminating the need for graphic cards
  • Highly reliable displays designed for 24/7 operation, with simple, easy-to-use special wall mount
  • Mobile solution provides a quick and easy, cost-effi cient video wall calibration through a mobile camera
  • Daisy-chaining technology extends content presentation capabilities without requiring external equipment
  • Optional wall mount allows for easier installation and disjoint.
  • Durable composition ensures messages run clearly and continuously

SPECIFICATIONS :

Display

Screen Size

46"

Panel Technology

D-LED DID

Resolution

1920 x 1080 (Full HD)

Pixel Pitch (mm)

0.53025mm(H) x 0.53025mm(V)

Active Display Area (mm)

1018.08mm x 572.67mm

Brightness

700nit

Contrast Ratio (Typical)

4000:1

Viewing Angle (H/V)

178º/178º

Response Time

8ms

Display Colors

8 bit - 16.7M

Color Gamut

72%

Haze

25% (Outer Haze 23%)

Display

Dynamic C/R

MEGA DCR

H-Scanning Frequency

30 ~ 81kHZ

V-Scanning Frequency

48 ~ 75Hz

Maximum Pixel Frequency

148.5MHz

Sound

Speaker Type

N/A

Connectivity

Input

RGB: Analog D-SUB, DVI-D, Display Port 1.2
Video: HDMI 2.0 (2)
HDCP: HDCP2.2
Audio: Stereo mini Jack
USB: Only F/W upgrade

Output

RGB: DP1.2(Loop-out)
Audio: Stereo mini Jack

External Control

RS232C(in/out), RJ45

Sensor

Detachable type (IR, Ambient)

Power

Type

Internal

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz

Power Consumption

Max [W/h]: 187
Typical [W/h]: 102
BTU (Max): 638
Sleep mode: less than 0.5W
Off mode: less than 0.5W

Environmental Conditions

Operating Temperature

0℃~ 40℃

Operating Humidity

10~80%

Recommended Usage Hours

24/7

Mechanical Specs.

Without Stand (W x H x D)

40.15" x 22.6" x 3.8" in

Package (WxHxD)

45.4" x 28.3" x 11.6" in

Product Weight

34.6 lbs

Package Weight

47.6 lbs

VESA Mount (mm)

600 x 400 (mm)

Bezel Width

1.15mm(U/L), 0.55mm(R/B)

Features

Special Features

Extreme Narrow Bezel

Special

ACM Support(Advanced Color Management), Auto Source Switching & Recovery, Haze 25%, Temperature Sensor, RS232C/RJ45 MDC,Plug and Play (DDC2B), Video Wall(15x15(OSD)), Video Wall Daisy Chain(10x10), Pivot Display, Image Rotation, Button Lock, DP 1.2 Digital Daisy Chain(Supporting UHD Resolution, HDCP support), Smart F/W update, Clock Battery(80hrs Clock Keeping)

Certification

Safety

UL (USA) : UL 60950-1 CSA (Canada) : CSA C22.2 No. 60950-1 TUV (Germany) : EN60950-1 NEMKO (Norway) : EN60950-1 KC (Korea) : K60950-1 CCC (China) : GB4943.1-2011 PSB (Singapore) : IEC60950-1 GOST (Russia) : IEC60950-1, EN55022 SIQ (Slovenia) : IEC60950-1, EN55022 PCBC (Poland) : IEC60590-1, EN55022 NOM (Mexico) : NOM-019-SCFI-1993 IRAM (Argentina) :IEC60950-1 SASO (Saudi Arabia) : IEC60950-1

EMC

FCC (USA) FCC Part 15, Subpart B class A CE (Europe) EN55022, EN55024 VCCI (Japan) V-3 (CISPR22) KCC (Korea) :KN22, KN24 BSMI (Taiwan) : CNS13438 (CISPR22) C-Tick (Australia) : AS/NZS3548 (CISPR22) CCC(China) :GB9254-2008, GB17625.1-2012

Accessory

Included in Box

Quick Setup Guide, Warranty Card, DP cable, stereo to DB9 cable, Power Cord, Remote Controller, Batteries

Optional

Mount: WMN-46VD

Pricing Notes:

  • Pricing and product availability subject to change without notice.
