Description
SAMSUNG WM55R FLIP 2 55IN 4K UHD USB TOUCH DISPLAY
UHD 4K High End Professional Display for AVSI & Digital Signage Projects - Integrated Touch with movable stand in 55"/ Auto Rotation/ Screen Mirroring/ Support Passive.
- 55” 4K UHD digital flipchart with a smooth and familiar pen-to-paper-like writing experience for making meetings and brainstorms more productive
- Touch out functionality allowing users to sync their personal devices with the Samsung Flip for real-time content sharing and control
- Stores your meeting securely, then lets you share all the notes via email, network, thumb drive or even printouts if you want
- Slim stand (sold separately)¹ offers increased working space in front of the display and more convenient ways to position and store than previous models
SPECIFICATIONS:
Series Name |
WM55R |
Display |
|
Screen Size |
55" |
Panel Technology |
60Hz New Edge |
Resolution |
3840 x 2160 (Landscape) |
Brightness |
350 nit (without glass), 220 nit (with glass) |
Contrast Ratio (Typical) |
4000:1 (Typ.)(without glass) |
Viewing Angle (H/V) |
178:178 |
Response Time |
8ms (Typ.) |
Connectivity |
|
Input |
VIDEO: Basic - HDMI (2) |
Output |
TOUCH OUT: Basic - Touch Out 1 (USB Upstream Type), Audio Out (1) |
External Control |
RS232C, LAN, WiFi/BT |
Sensor |
Basic - Acceleration Sensor |
Power Supply |
AC 100~240V 50/60Hz |
Power Consumption (Typical/Max) |
Typ: 100 W/h, Max: 181.5 W/h |
Power Consumption (Standby) |
0.5 W/h |
Environmental Conditions |
|
Operating Temperature |
0℃~ 40℃ |
Operating Humidity |
10~80% |
Features |
|
Key |
Flip App |
Special |
HARDWARE: Super Clear Coating, Temperature Sensor, Pivot Display, Clock Battery (168hrs Clock Keeping), Built in Speaker (10W x 2), Wi-Fi Module Embedded |
Touchscreen |
Yes |
Speaker Type |
Built in Speaker (10W x 2) |
SMART Signage Platform |
Yes |
Touch |
|
Type |
InGlass™ |
# of Drawing |
4 drawing (1024 level touch recognition) |
Touch Pen Type |
Passive Pen with magnet |
Object Recognition Range |
2mm/ 4mm / 8mm / 50mm , 1024 Level on Brush Mode |
Touch Response Time |
6.7ms |
Internal Player |
|
Processor |
CA72 Quad(1.7GHz) |
On-Chip Cache Memory |
L1 (I/D) : 32KB / 32KB |
Clock Speed |
1.7GHz CPU Quad |
Main Memory Interface |
LPDDR4 1.6GHz 64bit 2.5GB |
Graphics |
2D & 3D Graphics Engine |
Storage |
8GB |
IO Ports |
USB 2.0 |
Operating System |
Samsung Proprietary OS (VDLinux) |
Dimensions |
|
Without Stand (W x H x D) |
1297.4 x 768.2 x 59.9 mm |
Packaging (W x H x D) |
1464 x 915 x 190 mm |
Weight |
|
Product Weight |
28.2 kg |
Package Weight |
35.2 kg |
Accessories |
|
Included in Box |
Passive Pen(2), Power Cable, Touch Out Cable (USB upstream) |
Optional Wall Mount Kit |
WMN-6575SD |
Optional Stand |
WMN-WM55R |
Optional Tray |
CY-TF65BRC |
Specialty |
Flip UX |
Mechancial Specs |
|
VESA Mount |
400 x 400 |
Color |
Light Gray |
Protection Glass |
Yes |
Stand Type |
No-Gap Wall Mount |
Rotation |
Landscape only with Flip No-Gap Wallmount |
Power Cable Length |
3m |
Accessory |
Cover-Jack |
